Machines for sale


Offer of the new machine


WHN 13 P CNC

Control system: Heidenhain 640

Tool standard ISO 7 388 - AD (DIN 69 871/2)

Working spindle diameter ø 130 mm

Max. working spindle speed 3,000 rpm

Max. torque (S1 / S3-40%) 2,099 / 3,149 Nm

Slider cross section 400 x 400 mm

Spindle drive motor power (S1 / S3) 41 / 61.5 kW

Transverse travel of the table - X axis 3,500 mm

Vertical travel of the headstock - Y axis 2,000 mm

Longitudinal travel of the stand - Z axis 1,250 mm

Work spindle extension - W axis 730 mm

Working feed in all axes 8,000 mm / min

Rapid traverse in X, Y, Z, W axis 10,000 mm / min

Measuring the position of the X, Y and Z axes optical linear

Measuring the position of the B-axis optical angular

Measuring the position of the W axis rotary sensor on the motor

Measuring the position of the spindle axis C direct rotary encoder

Turntable (board size) 1600 x 1800 mm

Maximum table load 12 t

Working feed in B axis 0 - 2 rpm

Rapid traverse in B axis 2 rpm

Flush cooling - low pressure flow 62 l / min

Flush cooling - low pressure - outlet pressure 6 bar

Central axial cooling - high pressure - flow 25 l / min

Axial center cooling - high pressure - outlet pressure 20 bar

Total installed power 80 kVA

Type and power of Siemens S1 main engine 41 kW

Heidenhain TNC 640 control system

Handwheel for Heidenhain HR 510 CNC system

Control panel Vertical panel with integrated keyboard and LCD

Heidenhain linear measuring, optical, absolute for X, Y, Z axes

Remote diagnostics - preparation in the electrical cabinet

Fixed, fixed operator screen with integrated CNC panel


Accessories:

Spindle support sleeve 250 mm


Offer of the used lathe


ŠKODA SUT 126 NC Siemens 840 C, Ob 21 565, rebuilt in 1997

Basic machine parameters:

Running diameter above the slide: 1,000 mm

Running diameter above the bed: 1,260 mm

The slide is equipped with a lamella with the possibility of clamping the CAPTO C6 tool holders

Distance between centers: 14,500 mm

Maximum workpiece weight: 20 t

Siemens 840 C control system

Accessories: 5 pcs of rolling supports

Price of the EXW Plzeň machine, Czech Republic: 98,000 EUR

On request, we can add the price of disassembly, transportation, assembly.


Offer of the used portal


PBM 1640 CNC, Sinumerik 840D, r.v. 2011

Manufacturer: Fermat

Basic machine parameters:

Siemens control system: Sinumerik 840 D

Dimensions of the working surface of the table: 1600x4000 mm

Distance between columns: 2100 mm

Max. table load: 10,000 kg

X-axis travel: 4200 mm

Y-axis travel: 2300 mm

Z-axis travel: 1250 mm

Spindle taper: ISO 50.

Spindle speed: 40 - 6000 / min.

Max. spindle torque: 1050/1435 Nm

Rapid traverse: 10 m / min

Power of the main electric motor: 30/41 kW

Total power consumption: 79 kVA

Machine weight: 51000 kg

Dimensions L x W x H: 10480 x 5200 x 6120 mm

The machine is in very good technical condition.

Accessories:

C50 Universal milling head - manually adjustable. 1200 rpm, 15 kW, 100 Nm

N75 Vertical cutting head - manually adjustable. 2000 rpm, 11 kW, 200 Nm

On request, we can add the price of disassembly, transportation, assembly.
